Electrical Parameters

Input Voltage: AC100-240V, 50/60Hz

Rated Power: 200W

Power Interface: Waterproof 3-pin power cable, male and female, hand-in-hand cable, input/output

Signal Interface: Waterproof 3-pin signal cable, male and female, hand-in-hand cable, input/output

Channel Mode: 4 international standard DMX512 channels / extended mode 8 channels

Light Source

Light Source Specifications: 18 x 12W RGBW 4-in-1 LED beads

Lifespan: 50,000 hours

Optical System

Beam Angle: 25° 45° 60° (optional)

Strobe: 0-20Hz

Dimming: 0~100% electronic linear dimming

Color System

RGBW stepless color mixing, up to 16.7 million color variations

Control and Display System

Display: LED digital display

Control Method: Supports DMX512, RDM, auto run, master-slave

Appearance and Protection Level

Appearance: Die-cast aluminum alloy chassis

Protection Level: IP65

Other Functions

Heat Dissipation: Aluminum profile heatsink, featuring good heat dissipation, no noise, and energy-saving performance

Installation Method: Hanging type

Specifications

Product Dimensions: 1000*75*120mm (L×W×H) Net Weight: 5kg
