Electrical Parameters

Input Voltage: AC100-240V, 50/60Hz

Rated Power: 400W

Power Interface: Waterproof 3-pin power cable (male and female hand-in-hand), Input/Output

Signal Interface: Waterproof 3-pin signal cable (male and female hand-in-hand), Input/Output

Channel Mode: 4 international standard DMX512 channels / Expansion mode 16/48 channels

Light Source

Light Source Specification: 960 LED beads (864 pcs 0.3W RGB three-in-one LED + 96 pcs 3W white LED)

Life Span: 50,000 hours

Optical System

Strobe: 0-20HZ

Dimming: 0~100% electronic linear dimming

Color System

RGBW stepless color mixing, up to 16.7 million color variations

Control and Display System

Display: LED digital display

Control Mode: Supports DMX512, RDM, auto-run, master-slave

Appearance and Protection Level

Appearance: Die-cast aluminum alloy chassis

Protection Level: IP65

Other Functions

Heat Dissipation: Uses aluminum profile heat sink, featuring good heat dissipation, noiseless operation, and energy efficiency

Installation Method: Hanging type
